Adapter | Type 2 male - Type 1

Code: 31204
291 € 352,11 € incl. VAT
1 week delivery
Delivery to:
8.7.2022

Mode 3 adapter to connect charging station with connector Type 2 with a car that has a Type 1 connector. The cable has 6mm wires for charging with a maximum current of 32A / 7.4kW.

Detailed information

Product detailed description

Mode 3 adapter to connect charging station with connector Type 2 with a car that has a Type 1 connector. The cable has 6mm wires for charging with a maximum current of 32A / 7.4kW.



CAUTION: Does not work in conjunction with the Tesla WallBox, which is set by default. Legacy mode set up is needed.

Additional parameters

Category: Adapters
Weight: 2 kg
Input plug type: Type 2 | male
Output plug type: Type 1
Phase: 1 phase
Rated max. current: 32 A
Voltage: 230 V
Rated power: 3,7 - 7,4 kW
Housing: IP54
Cable length: 0,5 meter
Working temperature: - 40°C ~ + 75°C
Cable: 3x6,00mm2 + 1x0,75mm2
Usage: Inner / Outdoor
